Type：Inflow/Outflow
Model: AT0.6-AT4
Screen area(m²): 0.6-4
Screen cut scope(mm): 0.15-0.5
Inlet pressure(Mpa): 0.1-0.25
Pulping in-out concentration(%): 0.3-1.2
|
Model |
MW0.6 |
MW0.9 |
MW1.2 |
MW1.5 |
MW2 |
MW2.5 |
MW3.5 |
MW4.5 |
MW6 |
|
Inlet consistency(%) |
0.5-1.2 |
||||||||
|
Inlet pressure(MPa) |
0.1-0.3 |
||||||||
|
Motor Power(KW) |
15-22 |
18.5-30 |
22-37 |
30-45 |
37-55 |
37-75 |
45-110 |
55-132 |
75-160 |
|
Capacity(t/24h) |
20-30 |
25-60 |
30-80 |
40-120 |
80-210 |
100-230 |
140-280 |
180-350 |
230-500 |
